Chi tiết sản phẩm
Place of Origin: Guangdong, China
Hàng hiệu: EASY
Chứng nhận: CE Certification
Điều khoản thanh toán và vận chuyển
Minimum Order Quantity: 1
Giá bán: $24,000-26,000
Plate type: |
Screen Printer |
Automatic Grade: |
Automatic |
Printing colors: |
Two colors |
Voltage: |
380V |
Dimensions: |
145*145*200cm |
Weight: |
1400 KG |
Max print area: |
80*50mm |
Printing speed: |
45 pcs/min |
Model: |
SF-PSR18 |
Round size: |
(16-80)*(16-80)*H(10-40) |
Air pressure: |
0.6-0.8mpa |
Power: |
AC380V 50/60Hz 7Kw |
Core components: |
Bearing, motor, Pump, Gear, PLC, Pressure vessel, Engine, Gearbox |
Max speed: |
45 pcs/min |
Type: |
Servo |
Plate type: |
Screen Printer |
Automatic Grade: |
Automatic |
Printing colors: |
Two colors |
Voltage: |
380V |
Dimensions: |
145*145*200cm |
Weight: |
1400 KG |
Max print area: |
80*50mm |
Printing speed: |
45 pcs/min |
Model: |
SF-PSR18 |
Round size: |
(16-80)*(16-80)*H(10-40) |
Air pressure: |
0.6-0.8mpa |
Power: |
AC380V 50/60Hz 7Kw |
Core components: |
Bearing, motor, Pump, Gear, PLC, Pressure vessel, Engine, Gearbox |
Max speed: |
45 pcs/min |
Type: |
Servo |
| Attribute | Value |
|---|---|
| Plate Type | Screen Printer |
| Condition | New |
| Usage | Barrels Printer |
| Automatic Grade | Automatic |
| Color & Page | Two colors |
| Voltage | 380V |
| Dimensions (L×W×H) | 145×145×200cm |
| Weight | 1400 KG |
| Max. Print Area | 80×50mm |
| Warranty | 1 Year |
| Application | Caps Printer |
| Type | Servo |
| Printing Speed | 45 pcs/min |
| Core Components | Bearing, motor, Pump, Gear, PLC, Pressure vessel, Engine, Gearbox |
| Applicable Industries | Printing Shops, Printing Industry |
| Model | SF-PSR18 |
|---|---|
| Product Size (mm) | Round (16-80) × (16-80) × H (10-40) |
| Max. Speed | 45 pcs/min |
| Air Pressure | 0.6-0.8mpa |
| Power | AC380V 50/60Hz 7Kw |
The machine is securely packed in wooden cases for safe transportation.
Shen Fa (EASY®) company was founded in 1996 with a 50,000 sqm factory located in Huadu district of Guangzhou City. We specialize in fully-auto and semi-auto screen printing machines, hot-stamping machines, pad printing machines and related mechanical products.
Our facilities include research and development center, CNC processing machines, assembling and commissioning departments, sales and after-sale service departments. We hold AQSIQ and CE certifications and have obtained 9 patents for our auto 3 and 6 colors screen printing machines.
Pre-sale Service: Budget planning, cost-effective solutions, sample testing.
In-sale Service: Detailed design, technological information, production schedule, training courses.
After-sale Service: Free training, technical support, on-site guidance when needed, spare parts availability.
A: Please provide the following information for an accurate quote:
